Surface process:
Product specification | 2*PG1.5-4.8-3.3-0.7-0.8-1.2-0.8-5u"-25G | |
| texture of material | syringe needle | HBi59 Lead free copper |
| Needle tube | HBi59 Lead free copper | |
| Spring | SUS304 | |
| 50u"--100u"Ni+5u"Au | ||
| Rated voltage: | 12V | |
| Rated current: | 1A | |
| Contact resistance: | 30mΩ | |
| Salt spray requirements: | 48H | |
| Mechanical life: | More than 10000 times | |
Note: the surface treatment process can be designed according to the customer's test requirements
